Western Nanofabrication Facility

Scanning Electron Microscopy

The Nanofabrication Facility houses two Field Emission Scanning Electron Microscopes and can train users to perform SEM and also provides full-service SEM imaging, elemental analysis via Energy Dispersive X-ray (EDX) analysis and Focused Ion Beam (FIB) micro-machining.

There are three options for SEM imaging:
1) Drop off or send your samples to us for full-service imaging.
2) Make an appointment to be present while we image your samples.
3) Be trained to operate the SEM yourself.



Contact us for more information.
